1, Suitable for a wide range of belt width and thickness.
2, Suitable for wide general applications like conveyors used in quarry plant, gravel plant, cement, crushed stone plant, coal plant etc.
3, Effective and economic repairing parts for broken rubber conveyor belts.
4, Easy installation and repairing for the plate belt fasteners with common tools.
5, Cheap price, standard size, stable quality.
6, The steel plate fastener material is carbon steel with surface treatment yellow zinc plated, blue-white zinc plated.
Item | L | W | A | H | m | t | Net Weight |
mm | mm | mm | mm | mm | g/pc | ||
140# | 56.5 | 20.5 | 34 | 42.5 | M6 | 2 | 58 |
190# | 68 | 20.5 | 45 | 42.5 | M6 | 2 | 65 |
1 1/2'' | 69 | 27 | 42 | 49 | M8 | 2 | 96 |
2'' | 84 | 29 | 52 | 50 | M8 | 2 | 112 |
2 1/2'' | 114 | 39.5 | 70 | 58.5 | M8 | 3 | 234 |
Item | Belt Thickness | Tensile Strength | Min Pulley Dia. |
mm | N/mm | mm | |
140# | 5-11 | ≤400 | Φ250-360 |
190# | 8-14 | ≤600 | Φ260-460 |
1 1/2'' | 11-17 | ≤500 | Φ610-760 |
2'' | 14-21 | ≤750 | Φ1070 |
2 1/2'' | ≥24 | ≤1000 | Φ1220 |
