Plate Rubber Conveyor Belt Fastener, Size 140#
Plate Rubber Conveyor Belt Fastener, Size 140#
Plate Rubber Conveyor Belt Fastener, Size 140#
Plate Rubber Conveyor Belt Fastener, Size 140#
Plate Rubber Conveyor Belt Fastener, Size 140#
Plate Rubber Conveyor Belt Fastener, Size 140#

Keywords: Rubber Belt Fasteners, Rubber Conveyor Belt Fasteners, Belt Fasteners, Belt Lacing, Conveyor Belt Lacing, Rubber Belt Lacing, Bolt Solid Plate Fasteners

Introduction:

1, Suitable for a wide range of belt width and thickness.



2, Suitable for wide general applications like conveyors used in quarry plant, gravel plant, cement, crushed stone plant, coal plant etc.


3, Effective and economic repairing parts for broken rubber conveyor belts.



4, Easy installation and repairing for the plate belt fasteners with common tools.



5, Cheap price, standard size, stable quality.


6, The steel plate fastener material is carbon steel with surface treatment yellow zinc plated, blue-white zinc plated.


ItemLWAHmtNet Weight
mmmmmmmmmmg/pc
140#56.520.53442.5M6258
190#6820.54542.5M6265
1 1/2''69274249M8296
2''84295250M82112
2 1/2''11439.57058.5M83234


ItemBelt ThicknessTensile StrengthMin Pulley Dia.
mmN/mmmm
140#5-11≤400Φ250-360
190#8-14≤600Φ260-460
1 1/2''11-17≤500Φ610-760
2''14-21≤750Φ1070
2 1/2''≥24≤1000Φ1220
